Intercomp CS1500 - Scoreboard Connection Details; Connections to PCs and Displays

CS1500, Users
Rev T, June, 2010
Page 33 of 35
Pack C, SW 1 to 4:
Baud Rate C-1 C-2 C-3 C-4
9600 ON ON ON OFF
4800 OFF ON ON OFF
2400 ON ON OFF OFF
1200 OFF OFF ON OFF
600 ON OFF OFF ON
300 OFF ON OFF OFF
150 ON OFF OFF OFF
75 OFF OFF ON ON
The connection to an Intercomp S400 display is:
CS1500 S400
TXD (F) 2 (RXD)
GND (B) 7 (GND)
The connection to an Intercomp SA2000 display is:
CS1500 SA2000
TXD (F) 3
GND (B) 7
The connection to a 9-pin PC communication port is:
CS1500 PC 9-pin
TXD (F) 2
GND (B) 5
Note: For some setups it may be necessary to jump pins [6, 1, and 4] together, and pins
[7 and 8] together on the PC port connector.
The connection to a 25-pin PC communication port is:
CS1500 PC 25-pin
TXD (F) 3
GND (B) 7
Note: For some setups it may be necessary to jump pins [6, 8, and 20] together, and
pins [4 and 5] together on the PC port connector.
