Serial Output (Optional)
The CS1500 can be set to output either a scoreboard (continuous) or printer ticket
(demand). The default is a printer ticket, but this can be changed in the “calibration”
section “EE-02”.
The signal comes out of the 8-pin Serial I/O connector located on the side of the unit.
The connector has the following pinout:
Signal Pin
TXD F
GND B
The transmitted signal has the following characteristics:
Fixed 8 Data bits, no parity, 1 stop bit.
Baud rate is configurable under EE-03, see calibration section.
The output swings from -9 VDC to 9 VDC.
Scoreboard
The scoreboard output is an externally available signal designed to drive a numeric
overhead display board or a computer's RS-232 input.
Transmitted data: #xxxxxxx>0@ cr lf
The xxxxxxx field will vary in length depending on the length of the number and could
contain a decimal point and/or a minus sign. This data will be sent out about once a
second, with the exception that the transmission is delayed whenever there is motion.
Item Meaning ASCII Hex ASCII Decimal
# start character 23 35
xxxxxxx data
> separator 3E 62
0 data identifier 30 48
@ end character 40 64
<cr> carriage return 0D 13
<lf> linefeed 0A 10
