xGen Lite Installation and Programming Guide 7
NXG-1820 ACE classification
Type A
Physical Dimensions and Weight
Product
Main description
Dimensions (HxWxD)
Weight (g)
NXG-4(-RF)(-Z)
xGenLite /w metal enclosure
214 x 232 x 94 mm (enclosure
only)
359 x 232 x 94 mm (with
antennas)
1435 g
NXG-8(-Z)
NXG-8 /w standard metal
enclosure
292 x 291 x 91 mm
2075 g
NXG-8(-Z)-CB
NXG-8 /w large metal
enclosure
394 x 256 x 118 mm
7150 g
NXG-9-RF(-Z)
NXG-9 /w standard poly
housing
220 x 253 x 112 mm
1800 g
NXG-9(-RF)(-Z)-LB
NXG-9 /w large poly housing
394 x 256 x 118 mm
2800 g
NXG-8(-Z)-BO
NXG-8, board only
273 x 89 x 25 mm
210 g
NXG-4(-RF)(-Z)-BO
NXG-4, board only
192 x 89 x 25 mm
155 g
NXG-9(-RF)(-Z)-BO
NXG-9, board only
210 g
NXG-001
Plastic Enclosure
371 x 371 x 118 mm
1830 g
NXG-003(-G3)
Metal Enclosure
475 x 395 x 130 mm
7150 g
NXG-1820
Touchscreen keypad
18 x 82 x 125 mm
150 g
NXG-208
8 zone expander
135 x 80 x 55 mm
150 g
NXG-220
20 zone expander
135 x 80 x 64 mm
180 g
NXG-504
4 relay output expander
135 x 80 x 55 mm
150 g
NXG-510
10 relay output expander
135 x 80 x 64 mm
180 g
Fuses
Battery
4 A, resettable
12 V aux (combined for J2 BELL+, J2 AUX+, J7 AUX+)
xGen Lite 4
3 A, resettable
System LAN (combined for J2 POS, J3 POS)
xGen Lite 4
2 A, resettable
Mains, mains fuse
Note: Mains fuse is part of the mains terminal block.
500 mA, fast 20x5
Maintenance
No regular maintenance needed. System will report servicing when necessary.
