Email Sends an email to a specified address when there is a motion
detection alarm.
Note: You must configure email settings before check this
option. See “To set up the Email parameters:” on page 22. If
you want to send the event snapshot together with the email,
you should check the Attached Snapshot option.
Capture the image when an alarm is triggered and upload the
picture to NAS or FTP server.
Note: If you want to upload the snapshot to NAS, you must
configure NAS settings, If you want to upload the snapshot to
FTP, you must configure the FTP settings. Please ensure that
the Upload Type option is enabled.
Trigger external alarm outputs when an event occurs.
Note: This option is only supported by cameras that support
alarm output.
11. Click Save to save changes.
When you choose Advanced mode, you can set different sensitivities and
proportions on different areas. If you choose Auto-Switch or Schedule-Switch,
you can also set different settings for day and night or different periods.
To set up motion detection as advanced mode:
1. Click Configuration > Events > Motion Detection.
2. Check the Enable Motion Detection box. Check Enable Dynamic Analysis
for Motion if you want to see where has motion real-time.
Note: Select Disable for rules in local configuration menu if you don’t want the
detected objected displayed with the rectangles.
3. Select Advanced mode from the drop down menu.
4. Select OFF, Auto-switch or Scheduled-switch
5. Select Area No. and click Draw Area. Click and drag the mouse on the live
video image to draw an area sensitive to motion detection.
Note: You can draw up to 8 motion detection areas on the same image.
6. Click Stop Drawing to finish drawing. Click Clear All to delete all areas
marked and restart drawing.
7. Move the Sensitivity and Proportion of Object on Area slider to set the
sensitivity and proportion of the detection for different areas
8. Click Edit to edit the arming schedule. See the picture below for the editing
interface of the arming schedule.
