17
EN
Description of function
The DIN-rail timer is a timer that is installed on a DIN rail (Fig.1/
1
) by means of a click system; the
timer activates the connected device. The DIN-rail timer has one or two channels and can be operated
via a display (Fig.1/
5
) with four control buttons (Fig.1/
6
). The DIN-rail timer can be programmed
manually or via a mobile device. The radio signal frequency is 2.4GHz and the maximum transmission
power is 1.8mW.
Technical data (DIN EN 60730-1)
Mode of operation 1.B
Pollution degree 2
Rated impulse voltage 4000V
The technical data for the devices described in this manual can be found at:
http://qrc.graesslin.de/talento-smart-specs.
