Intermatic Grasslin talento smart B15 Operating Manual

16
Overview
A 110 – 230V 1 or 2-channel DIN-rail timer
B 12/24V DIN-rail timer
1
Click system for installation on a DIN rail
2
Terminals for channel 2 (only for 2-chan-
nel variant)
3
Terminal for phase
4
Sealable housing
5
Display
6
Control buttons
7
Terminal for neutral conductor
8
Terminals for channel 1
9
Potential-free empty terminal
Fig. 1: DIN-rail timer
1 1
7 98 8
A B
2 23 3 74 4
5 5
6 6
