Communications Reference
C-9
C
RS-232 Null Modem Cable for PC/XT (Part Number 048668)
SHIELD
PC
PRINTER
25-PIN (SOCKET) D-SUB
METAL BACKSHELL
25-PIN (PLUG) D-SUB
METAL BACKSHELL
NOTE: The metal backshell is connected directly
to the shield to achieve electrostatic discharge
(ESD) immunity.
CHASSIS GROUND
TRANSMITTED DATA
RECEIVED DATA
REQUEST TO SEND
CLEAR TO SEND
DATA SET READY
GROUND
DATA TERMINAL READY
CARRIER DETECT
CHASSIS GROUND
RECEIVED DATA
TRANSMITTED DATA
CARRIER DETECT
DATA TERMINAL READY
GROUND
DATA SET READY
CLEAR TO SEND
1
2
3
4
5
6
7
20
8
1
3
2
8
20
7
6
4
5
3XXXU.010
RS-232 Null Modem Cable for PC/AT (Part Number 048693)
SHIELD
AT
PRINTER
9-PIN (SOCKET) D-SUB
METAL BACKSHELL
25-PIN (PLUG) D-SUB
METAL BACKSHELL
NOTE: The metal backshell is connected directly
to the shield to achieve electrostatic discharge
(ESD) immunity.
RECEIVED DATA
TRANSMITTED DATA
CLEAR TO SEND
REQUEST TO SEND
DATA TERMINAL READY
DATA SET READY
CARRIER DETECT
GROUND
CHASSIS GROUND
TRANSMITTED DATA
RECEIVED DATA
CARRIER DETECT
DATA SET READY
DATA TERMINAL READY
CLEAR TO SEND
REQUEST TO SEND
GROUND
2
3
8
7
4
6
1
5
1
2
3
8
6
20
5
4
7
3XXXU.011

Intermec EasyCoder 3400e Specifications

Cutting Specifications

rating for 0.005-inch paper	1, 000, 000 cuts
rating for 0.010-inch paper	500, 000 cuts
cutting method	Guillotine-type blade

Dimensions and Mounting

adds to printer length	0.5 inch
minimum media width	0.75 inch
maximum media width	4.5 inches

Media Specifications

maximum media thickness	0.010 inch
minimum liner weight	40 lb
minimum cut length	1.0 inch
