Intermec EasyCoder F4 - Front View

Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1 9
Chapter 2 Installation
Front View
At the front of the printer are the display window, the control lamps,
and the keyboard. These features allow the operator to control and
set up the printer manually.
The printed labels, tickets, or tags are presented at the front of
the print mechanism.
Keyboard
Display Window
Side Door
Control Lamps
Print Mechanism
