Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 160
Chapter 11 Adjustments
The pressure of the thermal printhead against the ribbon or media is
factory-adjusted. However, the use of thicker or thinner media than
normal could require the printhead pressure to be readjusted.
Using a straight-slot screwdriver, turn the adjustment screw clockwise
for more pressure (+) or counterclockwise for less pressure (-). Print
a few labels and check the printout. Increased pressure generally
gives a darker printout and vice versa. Repeat until the desired
result is obtained.
To return to the factory setting, tighten the screw (+) as far as it goes
and then loosen it (-) six full turns.
Caution!
Do not use a higher printhead pressure than necessary because it
may increase the wear of the printhead and shorten its life.
Printhead
Pressure
Adjustment Screw
