Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 126
Chapter 4 Media Load
Peel-Off
(Self-strip)
Open the side door.
Turn the printhead lift lever clockwise to raise
the printhead.
The EasyCoder F4 can print on labels, tickets, tags, and continuous
stock in various forms. This chapter describes the case when
self-adhesive labels are separated from the liner immediately after
printing. The liner is then wound up on an integral liner takeup hub.
This is also known as “Self-strip” operation.
Peel-off operation cannot be performed when Quick-Load guides
are fi tted.
Peel-off can only be used for:
• Self-adhesive labels with liner
An optional label taken sensor can hold the printing of next label
in a batch until the present label has been removed, see Chapter
8, “Options.”
1 2
Important!
Save the label indicating the
sensitivity number attached to
the media roll. You will need
this number to set the media
sensitivity, see Appendix 2.
To Next Page
