Intermec EasyCoder F4 - Test;Service; Testprint

Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1 39
Chapter 6 Setting Up the Printer
Testprint
This part of the Setup Mode allows you to print various types of
test labels. Go to the desired option and select whether you want to
print all information or just a single format, page, udc, font. Press
<Enter> and the printer will start printing the test label or labels.
Press the <Pause> button to hold the printing temporarily. To
resume printing, press <Pause> again. To terminate the printing,
press <C>. The following options are available:
• Confi guration
Select between software (SW) and hardware (HW).
The Software Confi guration Label contains:
- Current confi guration parameters stored in the printer’s
memory
- Defi ned pages
- Defi ned formats
- Defi ned graphics
- Defi ned fonts
- Any installed printer options
The Hardware Confi guration Label contains:
- Printer memory information
- Printer mileage
- Printhead settings
- Firmware checksum, program, and version number
- Vertical lines for adjusting the printhead alignment
• Format
The Format Label contains a single format that you can use to
evaluate the print quality of a particular format. Select between
printing a single specifi ed format or labels for all the formats
stored in the printer’s memory.
• Page
The Page Label tests the ability of the printer to receive and print
single or multiple pages of label data that is sent from the host.
Select between printing a single specifi ed page or labels for all
the pages stored in the printer’s memory.
Setup Parameters, cont.
Test/Service
• Testprint
• Data Dump
• Memory Reset
• Label Rest Dots
• Form Adj Dots X
• Form Adj Dots Y
