EasyCoder PX4i and PX6i Service Manual 97

Chapter 8 — Print Unit

Headlift sensor

Headlift arm

Pressure adjuster

Linkage

Printhead lift lever

Return spring

Sensor arm

Printhead pressure

grub screw

(factory-adjustment)

EasyCoder PX6i

Headlift shaft
