Intermec EasyCoder PX4i Service Manual

Printing
Print Technique Direct Thermal and Thermal Transfer
Printhead Resolution 8 dots/mm (203.2 dpi) or
11.81 dots/mm (300 dpi) Not supported by IPL
Print Speed (variable)
100 to 300 mm/sec. (≈ 4 to 12 in./sec.)
Print Width (max) 112 mm (4.4 in.)
Print Length (max) 32767 dots
= 409.5 cm (161.25 in.) at 203.2 dpi
1
= 277.5 cm (109.23 in.) at 300 dpi
1
Media Width (min/max) 25 to 120 mm (1 to 4.72 in.)
Media Roll Diameter (max) 213 mm (8.38 in.)
205 mm (8.07 in.)
Tear-off & Cut-off
Peel-off & batch takeup
Media Roll Core Diameter 38 to 40 mm (1.5 in.) or
76 mm (3 in.) with adapter fi tted
Ribbon Width (min/max)
55 to 120 mm (2.16 to 4.72 in.)
Ribbon Roll Diameter (outer), max. 80 mm (3.15 in.)
≈ 450 m (1476 ft) length
Ribbon Roll Core Diameter (inner) 25 mm (1.00 in.)
Print Directions 4
Modes of Operation
Tear-Off (Straight-through) Yes
Cut-Off Option With cutter
Peel-Off (Self-strip) Option With rewinder
Internal Batch Takeup Option With rewinder
Fingerprint Firmware
Operating System Intermec Fingerprint v8.30 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Resident Scaleable Fonts 15 Unicode fonts
2
Resident Bar Codes 59
Startup Program (std) Intermec Shell v8.2
IPL Firmware
Operating System IPL v2.30
Smooth Fonts 13 scaleable + 21 simulated bitmap
Resident Bar Codes 44
Physical Measures
Dimensions (W × L × H) 275 × 482 × 238 mm
(10.8 × 19.0 × 9.4 in)
Weight (excluding media) 12.85 kg (28.4 pounds)
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Storage Temperature -20°C to +70°C (-4°F to +152°F)
Humidity 10 to 90% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 2 sockets for 4MB or 8MB each Std. 1 x 4MB
On-board SDRAM SIMM 1 socket for 16MB (Std. 16MB)
8 EasyCoder PX4i and PX6i Service Manual
Chapter 1 — Models and Options
1.2 EasyCoder PX4i Specifications

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
