EasyCoder PX4i and PX6i Service Manual 101

Chapter 8 — Print Unit

EasyCoder PX4i

EasyCoder PX6i

Wrinkling Turn Screwdriver

Inner side Counterclockwise

Outer side Clockwise

#T20 Torx screwdriver

Ribbon assist roller

#T20 Torx locking screw

#T20 Torx screwdriver

Ribbon assist roller

#T20 Torx locking screw
