Chapter 15 — CPU Board
The parameters sectors store the PFSVARs (see SETPFSVAR Fingerprint
statement), odometer values, and a few other “invisible” fi les with data,
that are required for the printer to start up with the same settings as when
it was shut off, for example information on the position of label gaps in
relation to the LSS.
The printer’s permanent memory can be expanded by fi tting a second
4MB or 8MB fl ash memory SIMMs in sockets J21. 4MB and 8MB fl ash
SIMMs can be mixed at will. Flash SIMMs are custom-made and can only
be ordered from Intermec.
Note: The fi rst time the printer is started with a SIMM in J21 (“EXP
FLASH”), the memory is not increased to enable cloning the fi rst SIMM.
The expansion is not done until the second time the printer is started.
Flash Memory Available to the User
J20 (Boot) J21 (Exp) J20 (Boot) J21 (Exp) SUM
4MB SIMM – 1.8MB – 1.8MB
4MB SIMM 4MB SIMM 1.8MB 4MB 5.8MB
4MB SIMM 8MB SIMM 1.8MB 8MB 9.8MB
8MB SIMM – 5.8MB – 5.8MB
8MB SIMM 4MB SIMM 5.8MB 4MB 9.8MB
8MB SIMM 8MB SIMM 5.8MB 8MB
13.8MB

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
