6 EasyCoder PX4i and PX6i Service Manual
Chapter 1 — Models and Options
Interfaces
The printers are as standard provided with one serial RS-232 port, one
serial USB port, and one wand interface. The wand interface is not sup-
ported by IPL. In addition, one EasyLAN interface and one or two extra
interface boards can be fi tted, see Chapter 14. IPL does only support one
EasyLAN interface and one parallel interface board.
Serial Port (RS-232)
USB Port
Provision for
one or two interface
boards (only the left
slot used with IPL)
Provision for Ether-
net connector
Wand interface
(not used with IPL)
Provision for Easy-
LAN antenna
