Intermec EasyCoder PX4i Service Manual

264 EasyCoder PX4i and PX6i Service Manual
Appendix B — Firmware Upgrading
Note: A special case is if the CompactFlash card already has a Fingerprint
fi rmware. Inserting such card will always install fi rmware in the printer
according to CompactFlash card. However, perhaps you like to install a
later fi rmware version picked from the web. If so, proceed like this:
1 Insert the CompactFlash card with a upgrade fi rmware on. Switch on
and wait for a completed upgrade and the normal startup of the printer
so you are in Fingerprint mode.
2 Activate the Shell program from "/rom" like this:
LOAD "/rom/SHELLXP.PRG"
MERGE "/rom/ERRHAND.PRG"
RUN
3 In Shell, select the option “UPDATE: COMPACT FLASH?” and press
<Enter>.
4 Send the .bin or .uff fi le from the host using zmodem.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
