Intermec EasyCoder PX4i Service Manual

&%%$
$)2%#4)/.
$OT
$OTLINE
ONPRINTHEAD
$OT
MMIN
0RINT7IDTH
MAXMMIN
-EDIA7IDTH
MMIN
EasyCoder PX4i and PX6i Service Manual 87
Chapter 8 — Print Unit
11.81 dots/mm Printhead (not IPL)
Density 11.81 dots/mm (300 dots per inch)
Print width 112 mm (4.4 inches)
Number of dots 1322
Dot size 0.085 mm (3.33 mils)

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
