Chapter 2 — Set Up the Printer
54 PC23 and PC43 Desktop Printer User Manual
Load Ribbon
1 Press the printer latches toward the front of the printer and open
the printer lid.
2 If there is an empty ribbon core in the media compartment, remove
the core and set it aside.
3 Remove and discard the full ribbon takeup core.
Note: The PC43t only supports “ink out” operation.
