16 ZSim v5.XX User‘s Guide
Default: On
Optimize Image Magnification
Purpose: It is highly recommended to use an Intermec printer
with the same printhead resolution as the replaced
Zebra printer. In case of replacing a 152 dpi Zebra
printer, use an Intermec printer with 300 dpi
printhead.
If not using a compatible resolution, images will not
print correctly,
If you want to increase the size of printed images, for
example double the size, you can adjust this with the
function On/Off.
Default:
Off
Paper Type
Purpose: Sets the type of paper used in the printer. You can
set this command to ermal Transfer or Direct
ermal. You set this parameter during the Initial
Setup Configuration process.
Peel Off Length
Purpose: Sets the default distance the label should stop before
the tear off bar when the printer is in Peel Off mode
in [dots].
Default: PF2/4i PM4i PX4/6i PD41
203 dpi: 44 dots 44 44 60
300 dpi: 60 dots 66 60 100
Permanent Save
Purpose: Causes the ZSim program to store all downloaded
formats and images permanently in the printer’s
memory. e next time you start up the printer, your
saved formats and images are loaded and ready for
use.
Note:
If you are downloading your graphics or
formats as you print, turn off Permanent Save to
increase processing speed.
Turning Permanent Save off does not delete the saved
