Appendix A — Specifications
134 PF2i and PF4i Mid-Range Printer User’s Manual
Self-Adhesive Strip
Liner (b)
The liner must not extend more than a total of 1.6 mm (0.06 in)
outside the face material and should protrude equally on both sides.
PF2i Media Width Including Liner (a)
Measurement Value
Maximum 60 mm (2.36 in)
Minimum, standard guides 25.0 mm (1.00 in)
Minimum, quick-load guides 40 mm (1.57 in)
PF4i Media Width Including Liner (a)
Measurement Value
Maximum 114.3 mm (4.50 in)
Minimum, standard guides 25.0 mm (1.00 in)
Minimum, quick-load guides 40 mm (1.57 in)
Minimum, wide quick-load guides 80.0 mm (3.15 in)
PF2i Media Width Excluding Liner (c)
Measurement Value
Maximum 58.4 mm (2.30 in)
Minimum 23.8 mm (0.94 in)
PF4i Media Width Excluding Liner (c)
Measurement Value
Maximum 112.7 mm (4.43 in)
Minimum 23.8 mm (0.94 in)
