Appendix A — Specifications
PF2i and PF4i Mid-Range Printer User’s Manual 137
The Label Stop Sensor (LSS) must be able to detect the extreme front
edges of the labels.
Label Length (d)
Measurement Value
Maximum Dependent on SDRAM size
Minimum 8.0 mm (0.32 in)
Note: Under ideal circumstances, a minimum label length of 4 mm
(0.16 in) could be used. It requires the sum of the label length (d) and
the label gap (e) to be larger than 7 mm (0.28 in), that batch printing is
used, and that no pull back of the media is performed. Intermec does
not guarantee that such short labels will work, but it is up to users to
test this in their unique application.
Label Gap (e)
Measurement Value
Maximum 21.3 mm (0.83 in)
Recommended 3.0 mm (0.12 in)
Minimum 1.2 mm (0.05 in)
