(193GS) MODEL SF90220T SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/03/2016
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
REF. NO. DESCRIPTION QTY.
SPARE PART NO.
1 PRESSURE GAUGE 1 11720
2 TANK COVER & 6-WAY VALVE SET 1 11721
3 DRAIN OUTLET COVER 1 11131
4 CLAMP ASSEMBLY 1 11722
5 TANK O-RING 1 11728
6 SAND FILTER PUMP MOTOR INLET O-RING 1 10712
7 CENTER PIPE 1 11729
8 FILTER GRID 1 11730
9 DRAIN VALVE CAP 1 11456
10 DRAIN VALVE O-RING 1 11385
11 L-SHAPE O-RING 4 11228
12* HOSE WITH NUTS 2 11010
13 SAND FILTER INTERCONNECETING HOSE 1 11764
14 TRANSPARENT OUTLET ADAPTOR 2 11723
15 TRANSPARENT OUTLET ADAPTOR O-RING 4 11724
16 CLAMP PIN 1 11726
17 CLAMP SCREW 1 11727
18 L-SHAPE O-RING 1 11412
19 TRANSPARENT LEAF TRAP 1 11733
20 PUMP MOTOR 1 11735GS
21* PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747
22* HOSE O-RING 2 10262
23* STEP WASHER 2 10745
24* STRAINER NUT 2 10256
25* FLAT STRAINER RUBBER WASHER 2 10255
26* THREADED STRAINER CONNECTOR 1 11235
27* ADJUSTABLE POOL INLET JET NOZZLE 1 12369
28* ADAPTOR B 2 10722
29* STRAINER CONNECTOR 1 11070
30* POOL INLET JET NOZZLE 1 12364
31* STRAINER GRID 1 12197
32 10" SAND FILTER PUMP TANK 1 11731
33 10" SAND FILTER PUMP TANK BASE 1 11732
34 TRANSPARENT OUTLET ADAPTOR SCREW 4 11725
35 AIR RELEASE VALVE 1 10725
36 AIR RELEASE VALVE O-RING 1 10264
37* STRAINER GRID 1 12198
38* AIR JET VALVE 1 12363
39* INLET THREADED AIR CONNECTOR 1 12371
40* POOL INLET AIR ADAPTOR 1 12368
41* INLET STRAINER CONNECTOR 1 12365
42* AIR JET VALVE CAP (NOT SHOWN) 1 12373
Page 5
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.
