SAVE THESE INSTRUCTIONS
English
Page 14
SALTWATER SYSTEM STATIONARY MOUNTING
Some countries, especially in the European community, require the product to be
secured to the ground or to a base in a permanent upright position. Check with
your local authorities to determine if there is a regulation in your area regarding
above-the-ground swimming pool fi lter pumps. If yes, then the product can be
mounted to a platform using the two holes located in the base. See drawing
below.
The product can be mounted on a cement base or onto a wooden platform to
prevent accidental tipping. Total assembly must exceed 18kg.
1.
The mounting holes are 6.4 mm in diameter and spaced 62 mm apart.
2.
Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
62 mm
