SAVE THESE INSTRUCTIONS
English
(132) MODEL CS8220/8230 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/29/2013
Page 19
SALTWATER SYSTEM STATIONARY MOUNTING
Some countries, especially in the European community, require the product to be
secured to the ground or to a base in a permanent upright position. Check with
your local authorities to determine if there is a regulation in your area regarding
above-the-ground swimming pool filter pumps. If yes, then the product can be
mounted to a platform using the two holes located in the base. See drawing
below.
The product can be mounted on a cement base or onto a wooden platform to
prevent accidental tipping. Total assembly must exceed 18kg .
1. The mounting holes are 6.4 mm in diameter and spaced 97 mm apart.
2. Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
97 mm
