Section 3: Operation
Revision 1.4 29 © 2009 Intuicom, Inc.
MDM – Indicates a successful connection to the carrier’s IP network (and thus the Internet)
SVR – Indicates a successful network connection to the IP socket (either RAW or NTRIP).
TXD – Indicates data being transmitted out the internal Intuicom Wireless Data Radio,
and/or the Data port (2) on the front panel.
1 – 4 –In normal operation, the LEDs labeled 1-4 indicate the currently selected Profile. In
antenna alignment mode, the LEDs are used as a bar graph to indicate cellular signal
strength.
