Section 1: Overview

1.3 Example Applications

Spider/VRS/

NTRIP Caster

Intuicom RTK Bridge - Cellular

Intuicom 900 MHz

Spread Spectrum

Wireless Data

RTK Rover

Machine

Control

Construction

Agriculture

RTCM 3.x

RTCM 2.x

CMR/CMR+

Leica

Internet

L1 GPS

Antenna

CDMA/GSM

GSM/CDMA

Wireless Internet/Data

RTK Corrections

Figure 1-2: Intuicom Wireless RTK Bridge - Cellular Architecture Overview

Typical Application - The Intuicom Wireless RTK Bridge has a flexible configuration

and can be used to satisfy a range of connectivity needs. Typical installations have the

RTK Bridge configured to connect to an NTRIP Caster where it provides mountpoint and

authentication information. Once connected to a mountpoint, it will stream its GPS point

position (from its internal L1 GPS) allowing the Network Correction Server (such as

Leica Spider) to generate individualized corrections or create a virtual reference station.

The unit receives these corrections via IP and then broadcasts them to receiving RTK

rover units.
