Invacare®Action3Junior
3.7.1Armrest,steplessheightadjustable,removable
Removing
1.Applytheparkingbrakeonbothsides.
2.PreviouslypressonthelockingmechanismAlocated
atthebottomofthearmrestverticalbracket(ifso
equipped).
3.Pullthearmrestbythearmcushionoutoftheholder.
4.Toadjusthoweasyordifcultitistopullthearmrest
outoftheholder,changethedegreetowhichthe
screwsDaretightened.
Fitting
1.Pushthearmrestintotheholder .
Adjustingtheheight
1.LoosenthescrewBwith5mmAllenkeyinthegroove
Cofthearmresttube.
2.Movethearmrestupwardsordownwardsuntilyou
reachthedesiredheight,whilekeepingscrewBin
place(atthetopedgeoftheholder).
3.TightenthescrewB(5–6Nm).
4.Performthesettingonbothsides.
3.8Legrests
WARNING!
Riskofinjury
–Neverliftthewheelchairbythefootrest
supportsorlegrests.
CAUTION!
Riskofpinchingorcrushingngers
Thereareswingmechanismswhereyoucould
trapyourngers.
–Becarefulwhenusing,swinging,disassembling
oradjustingthesemechanisms.
IMPORTANT!
Riskofdamagetothelegrestmechanism
–Donotplaceanythingheavy,orletchildren
sitonthelegrest.
