Invacare Action 3 Junior - Transfer Kit Wheels; Air Pump

Options
1.InsertthetubeAofthetabletrayintoitssupportB
belowthearmpad.
2.Slidethetabletrayforwardsorbackwardstoadjustto
therequireddepth.
3.FirmlytightentheknobC.
CAUTION!
Riskofdiscomfort
–Whenadjustingthedepthofthetable,make
surenottosqueezethestomachoftheuser.
Adjustingsideways
Thetabletrayhavetobeadjustedsidewaystot
theseatwidthofthechairandtheuserposture.
CAUTION!
Riskofdiscomfort
–Thesidewaysadjustmentofthetabletraymust
becarriedoutbyaqualiedtechnician.
4.8Transferkitwheels
Ifyourwheelchairistoowideforcertainapplications,e.g.
trains/aeroplanes,narrowpassageways,narrowdoors,the
transferkitwheelscanbeused.
WARNING!
–Whenusingtransferkitwheels,theparking
brakesnolongerhaveanyeffectandyou
cannotcontrolyourwheelchairviathe
handrims.
Thetransferkitwheelsareattacheddirectlytotherear
frameasanoption.
WARNING!
Riskoftippingsidewards
–Makesurethatanti-tipperswithtransferkit
wheelsareinstalledonbothsidesofthe
wheelchair.
SwitchingtoTransferkitwheels
1.Activatetheanti-tipperswithtransferkitwheelson
bothsides,
→3.9Anti-tipper,page23.
2.Withthehelpofanassistant,removetherearwheel,
→7.4Removingandttingtherearwheels,page45
andlowerthewheelchairtothetransferkitwheel.
3.Repeattheprocessontheotherside.
SwitchingfromTransferkitwheelstorearwheels
1.Withthehelpofanassistant,ttherearwheelback
ontotheremovableaxle,
→7.4Removingandttingtherearwheels,page45
andlowerthewheelchairtotherearwheel.
2.Repeattheprocessontheotherside.
4.9Airpump
Theairpumpisttedwithauniversalvalveconnection.
1.Removethedustcapfromthevalveconnection.
2.Pushthevalveconnectionontotheopenvalveonthe
wheelandpumpthewheelup.
1608517-C31
