Invacare Action 3 Junior - 11 Technical Data; Dimensions and Weight

TechnicalData
11TechnicalData
11.1Dimensionsandweight
Alldimensionanweightspecicationsrefertoawiderange
ofthewheelchairinastandardconguration.Dimension
andweight(basedonISO7176–1/5/7)mayalteraccording
todifferentcongurations.
IMPORTANT!
–Insomecongurations,theoveralldimensions
ofthewheelchairwhenitisreadyforuse
exceedstheauthorisedlimitsandtheaccessto
emergencyescaperoutesisnotpossible.
–Insomecongurations,thewheelchairexceeds
thesizerecommendedfortravellingbytrain
intheEU.
Maximumuserweight80kg
A
Overalllengthwithleg
rests
690–1000mm
B
Overallwidth
365–585mm
Foldedlength
690–1000mm
Foldedwidth
315mm
Foldedheight
870–1130mm
Totalmassfrom13,5–15,5kg
Massoftheheaviest
part
8–12kg
Staticstability
Downhill:0°–7°
Uphill:0°–16°
Sideways:0°–15°
Seatplaneangle
1,5°–8,5°
C
Effectiveseatdepth
200–375mm
D
Effectiveseatwidth
205–380mm,
inincrementsof25mm
E
Seatsurfaceheightat
frontedge
410–460mm,
inincrementsof25mm
F
Seatsurfaceheightat
rearedge
335–440mm,
inincrementsof25mm
G
Backrestangle
Range:0°/+30°
Fixed:90°(+7°)
Recliner:90°(0°/+30°)mm,
inincrementsof10°
1608517-C59
