Invacare Action 3 Junior - Anti-tipper Functionality

ProductOverview
•Onepiecefootboard
Heightadjustment:
1.LooseningthexingboltBwith5mmAllenKey
and10mmspanner .
2.Adjustintooneofpresetpositionsandtightenthe
xingbolt(5Nm)Bintothedesiredposition.
Angleadjustment:
1.AfterlooseningthexingscrewDwith5mm
Allenkey.
2.Adjusttheanglepositionsandrmlytightenthe
xingscrewD(12Nm)intothedesiredposition.
Invacarerecommendsthatfootplateadjustmentiscarried
outbyaqualiedtechnician.
Toensureagoodpositionofthefeet,twotypes
ofstrapscanbeprovided;theheelstrap(serial)
andthecalfstrap(optional)attachedtothelegrest
support.Bothadjustablebyhookandloopfasteners.
3.9Anti-tipper
Ananti-tipperpreventsthewheelchairfromtipping
backwards.
WARNING!
Riskofoverturning
Anti-tippersthatareincorrectlysetornolonger
workingcanleadtooverturning.
–Alwayscheckthattheanti-tipperisworking
beforeusingthewheelchairandhaveitset
orreadjustedbyaqualiedtechnicianwhen
required.
–Insomecongurations,thestaticstabilityof
thewheelchairmaybelowerthan10°;Invacare
stronglyrecommendstheuseofanti-tipper
(availableasanoption).
WARNING!
Riskofoverturning
Onunevenorsoftground,theanti-tippercansink
intopotholesordirectlyintotheground,thereby
curtailingoreliminatingitssafetyfunction.
–Onlyusetheanti-tipperwhentravellingon
evenandrmground.
IMPORTANT!
Riskofdamage
–Neverstepontheanti-tipperoruseitasa
tippingaid.
