Invacare®Action3Junior
Activatingtheanti-tipper
1.ReleasethespringbuttonAandswiveltheanti-tipper
downwardsuntilitengagesandthefrontreleasebutton
Bsnapsintotheframehole.
2.EnsurefrontreleasebuttonBprotrudesfullythrough
framehole.
WARNING!
Riskoftipping
Anactivatedanti-tippercancatchwhen
negotiatingasteporanedge.
–Alwaysdeactivatetheanti-tipperbeforedriving
overasteporkerb.
Deactivatingtheanti-tipper
1.ReleasethespringbuttonAandswiveltheanti-tipper
upwardsuntilitengagesandthefrontreleasebuttonB
snapsintotheframehole.
WARNING!
Riskofoverturning
–Alwaysadvisetheuserifyoudeactivatethe
anti-tippers.
Thereisaredlabelonthehousingoftheanti-tipper,
thislabelshowswhentheanti-tipperisinactivated.
Whentheanti-tipperiscorrectlyactivated,thered
labelwillbeconcealed.
Settingtheheight
WARNING!
Riskofoverturning
–Theadjustmentsoftheanti-tippermustbe
carriedoutbyaqualiedtechnician.
Thisadjustmentisrequiredwithreferencetothe
positionanddiameteroftherearwheelaswellas
theuserconditionsandhisparticularsafetylimits.
Makesurethattheanti-tipperdeviceistted
correctlyoneachside(ifapplicable),thespring
buttonAandxationCmustbelockedinto
position.
