Invacare®CarrollCSSeries™
9.76inBedOnly-Tightenthefastenerswithtwo7/16inwrenches.
Repositiontheotherthreebracketsandreapplytheends.
AllModelsExceptCS9FX600
ModelCS9FX600
10.Positionthemattressonthedeck.
11.Pressthemattressinsidethemattresskeeper.Ensurethe
mattressisengagedonallfourcorners.
4.3InstallingtheHeadandFootEnds
Headandfootendsarenormallypackagedtogethereitherin
acardboardboxoronawoodenskidseparatefromthebed.
BedendmodelIHBEADJmustbeusedwithbedmodel
CS9FX600.6.10RefertoAdjustingtheHeadBoardWidth
forCS9FX600onpage62,page54
.
1.Removethekeyfromthekeyhole.
Bedendnotshown.
341153410-N~00
