Invacare Carroll CS3 - Foot Pad Lock Mechanism; Bed Steer Mechanism

Usage
5.5FootPadLockMechanism
ForCS3ModelOnly
CAUTION!
RiskofDamage
Movingthebedwhilethefloorlock,casterlock,orfoot
padisengagedmayDAMAGEthebed.Toavoid:
–DONOTmovethebedunlessthefloorlock,caster
lock,orfootpadisdisengaged(unlocked).
Mobility
BedattheLowestPosition
StabilityRange
5.6BedSteerMechanism
1.Steermechanismisoneithersideoftheheadendofthebed.
1153410-N~0043
