SERVICE MANUAL
Invacare
®
- Comet
30
7.6 Replacing steering column/fork 3-wheel
ATTENTION! Risk of accident.
Accidental rolling can lead to accidents.
• Secure the scooter against rolling away.
NOTE:
When disassembling, note the position of small parts such as screws and washers. Put small
parts down so that they can be reassembled in the right sequence.
Requirements:
• Open spanner, 10 mm.
• Open spanner, 17 mm.
• Open spanner, 19 mm.
• Open spanner, 32 mm.
• Phillips screwdriver
• Supporting wooden block
• Remove the seat.
• Remove motor cover.
• Separate battery cable.
• Place a supporting wooden block under the
front part of the frame so that the front wheel
is no longer touching the floor.
