Invacare
®
- Comet
SERVICE MANUAL
37
7.8 Replacing brake cable
ATTENTION! Risk of accident.
Accidental rolling can lead to accidents.
• Secure the scooter against rolling away.
NOTE:
When disassembling, note the position of small parts such as screws and washers. Put small
parts down so that they can be reassembled in the right sequence.
Requirements:
• Open spanner, 10 mm.
• Phillips screwdriver
• Decrease the brake tension on the wheel
using the setting screw (1).
• Disconnect the brake cable at the wheel (2).
• Disconnect brake cable at steering wheel
brake lever.
• Route the brake cable through the cladding.
• Loosen brake lever screw (3) at wheel.
• Replace brake cable.
• Reassembly of the brake cable takes place
in reverse order.
• Check braking function while pushing.
