SERVICE MANUAL
Invacare
®
- Comet
40
7.10 Replacing steering linkage/steering rod
ATTENTION! Risk of accident.
Accidental rolling can lead to accidents.
• Secure the scooter against rolling away.
NOTE:
When disassembling, note the position of small parts such as screws and washers. Put small
parts down so that they can be reassembled in the right sequence.
Requirements:
• Open spanner, 10 mm.
• Open spanner, 12 mm.
• Open spanner, 13 mm.
• Phillips screwdriver
• Circlip pliers
• Supporting wooden block
• Remove motor cover.
• Disconnect battery cable (1).
• Dismantle the steering column and the
chassis (see chapter entitled "Replacing
steering column/fork 3-wheel" on page
30).
