Invacare Comet - Seat Rotation and Removal

SERVICE MANUAL
Invacare
®
- Comet
50
Setting the potentiometer to the middle
position:
• Loosen the bolts (1) on the drive lever
mounting.
• Twist the potentiometer shaft (2) until the
same resistance (approx. 5kOhm) is
measured between the central connection
cable (3) and both outputs (4).
• Retighten the bolts on the drive lever
mounting.
• Check settings and repeat the adjustment if
necessary.
• Reassembly of the operating console takes
place in reverse order
• Check all functions (trial run).
