10
PART TWO
INITIAL SETUP
PROCEDURE 2
FIGURE 3 - CONNECTING THE COMPRESSOR TO
THE CONCENTRATOR
Metal Tab
Inlet/Outlet Fitting
Compressor
Inlet Fitting
Interconnect Hose
Insert End of Interconnect
Hose into Inlet/Outlet Fitting
Concentrator
Power
Cord
Outlet
Fitting
