15
PART TWO
FIGURE 3 - CONNECTING THE CYLINDER TO THE
COMPRESSOR
Connector
Fillport
Cylinder
Cylinder Fillport
Regulator Flow
Knob
➞
Cylinder Gauge
NOTE: Connector fillport cover not shown for clarity.
Compressor
Cradle
PROCEDURE 3COMPRESSOR OPERATION
