17
PART TWO
TURNING THE COMPRESSOR ON
(CONTINUED)
NOTE: If the ATTENTION (red) light and audible alarm are on. Refer to the
TROUBLESHOOTING section of the Homefill II owners manual (part no.
1100873).
6. Remove the full cylinder. Refer to
REMOVING THE CYLINDER in
this instruction sheet.
Control
Panel
ATTENTION
(Red Light and
Audible Alarm)
O
2
BELOW NORMAL
(Yellow Light)
FULL
(Green Light)
FILLING
(Green Light)
WAIT
(Yellow Light)
Power
Switch
FIGURE 3 - TURNING THE COMPRESSOR ON
USE NO OIL
I
O
O2 BELOW NORMAL
PROCEDURE 3COMPRESSOR OPERATION
To Next Page
