Invacare Topan - Angle Adjustable Legrest; Adjusting the Angle of the Legrest

59
8.5.3 Angle adjustable legrest
8.5.3.1 Adjusting the angle of the legrest
Pre-requisites:
• 1x open-ended spanner 13 mm
• 1x open-ended spanner 10 mm
• 1x Allen key 4 mm
• Loosen the fixation screws (1) of the pivotal points of
the angel adjustment, using the open-ended spanner
10 mm and the Allen key 4 mm.
• Loosen the clamping screw (2) of the angle adjustment,
using the open-ended spanner 13 mm.
