67
8.5.5.3 Adjusting the height of the swing-away calf plate
Pre-requisites:
• 1x Phillips screwdriver
The height adjustment the calf support is infinitely variable.
• Loosen the screws (1) using the Phillips screwdriver.
• Set the calf support to the desired height.
• Re-tighten the screws.
