148
12.1.2 Repairing a flat tyre at the front (tyre type 280/250-4)
Requirements:
• Allen key 5 mm
• Open-end spanner 13 mm
• Repair kit for inner tube tyres or a new inner tube
• Talcum powder
Removing the wheel
• Jack up the vehicle (place a wooden wedge under
the frame).
• Loosen and remove the screw (1) using the Allen key
on one side and the open-ended spanner on the
other side (for countering).
• Pull the wheel from the fork
NOTE
Installation is carried out in reverse order. Please ensure that the wheel is re-fitted on the same
side and in the same running direction as removed.
