63
8.3 Manually adjusting the backrest
8.3.1 Adjusting the backrest using the gas pressure spring
The lever for adjusting the backrest is located on the opposite side from the Joystick Box under the
armrest.
Adjusting angle of the backrest
• Pull lever (1) upward.
• Adjust backrest angle by leaning forward or
backward.
• Release the lever again. The backrest is locked at
the desired angle.
NOTE
If the lever is pulled upwards and inwards at the same time, it will latch into a notch at the top.
Push the lever out of the notch to release it, and allow it to be moved down again.
