9.1.2 Adjustable legrest
9.1.2.1 Adjusting the angle
Prerequisites:
• 1x 10 mm open-ended spanner
• Use the open-ended spanner to loosen the counternut
(1).
• Move the legrest to the desired position by turning the
spindle (2).
• Tighten the counternut.
