6.2 Manually disengaging gearless motors (emergency disengaging)
Danger of the vehicle running away!
• When the motors are disengaged (for push operation whilst freewheeling), the
electromagnetic motor brakes are deactivated! When the vehicle is parked, the levers for
engaging and disengaging the motors must without fail be locked firmly into the "DRIVE"
position (electromagnetic motor brakes activated)!
The levers for disengaging the motors are located behind the drive wheels.
Disengaging the motors:
• Switch off the remote.
• Pull the locking pin (1) out and pull the engaging lever (2) backwards. The motor is disengaged.
Engaging the motors:
• Push the coupling lever (1) to the front. The motor is engaged.
