Temperature monitoring disables the System operation if the Handpiece
sapphire temperature is outside the operating range for Diolaze and DiolazeXL
and Lumecca Handpieces.
The power electronics cannot be fully activated unless the laser or RF Handpieces
and Footswitch have been connected to the System. With IPL Handpieces, the
connection of the Applicator is sufficient.
Diolaze and DiolazeXL Handpieces contains a comprehensive monitoring system
that allows operation only when numerous safety conditions have been met. A
fault must be corrected and the system reset before laser operation is re-
enabled. Monitoring includes the following:
Remote Interlock allows laser emission only when there is electrical continuity
across the contacts of the remote Interlock Connector (located on the rear of the
Console). The System is shipped with a remote Interlock Jumper already
connected, providing electrical continuity and allowing the laser to operate. To
set up a remote Interlock Switch, such as on the treatment room door, please
contact qualified personnel.
The Diolaze and DiolazeXL Hand Triggers allow laser emission only when the
Footswitch is pressed.
Laser Energy monitoring to verify that the laser output is within specific energy
tolerances for every laser pulse. If abnormally low or high, the laser current
(indicative of optical energy) is detected, a System fault is triggered, and the user
is notified.
As a safety feature and in compliance with U.S. and international regulations, the
Diolaze and DiolazeXL Handpieces contain an Electronic Shutter to help prevent
inadvertent laser emissions. The Shutter which is located on the Console, is an
electronic switch that is independent of, and in addition to, the normal energy
circuit for the laser when it is ON.
Releasing the Diolaze and DiolazeXL Handpiece Trigger will stop laser emissions.
In the event of an emergency, the laser can be shut down immediately by
pushing the Emergency Stop Button located on the Console. To restore
operations, rotate the Button clockwise until it pops out again. Then follow the
standard startup sequence. Since the Emergency Stop Button is not intended for
routine use, please follow the procedure in the System Operation Section for
normal shutdown.
For the RF applications:
There is skin temperature monitoring for Forma, Plus, and BodyFX/MiniFX.
There is vacuum level monitoring for BodyFX/MiniFX. RF is disabled when the
vacuum is below the predetermined level.
