InMode Without Vasculaze Operator Manual
Section 8: Lumecca Treatment
Information
51 of 96
Skin
type
Lesions
type
Handpiece
Fluence
Pulse
width
Cooling
I-II
Pigmented
lesions
515nm
8-
12J/cm²
Short
Long
Strong
Vascular
lesions
515nm
12-
16J/cm²
Short
Long
Strong
III-IV
Pigmented
lesions
580nm
6-
12J/cm²
Short
Long
Strong
Vascular
lesions
580nm
10-
16J/cm²
Long
Strong
Always start with a low settings level to check patient tolerance to the
treatment parameters, test and then gradually increase energy fluence to
reach the results without compromising safety.
Apply the Handpiece to the treated. Use slight pressure and activate the Hand
Trigger Button to deliver a light pulse.
Perform a test spot in the area to be treated on a non-conspicuous spot and
wait 10-15 minutes to check the response.
In a single mode (AutoRepeat Off) - move Handpiece to adjacent area without
overlap and apply next pulse to cover all treatment area.
 In a continuous mode - slide the Handpiece to adjacent area without overlap
and chose Auto Repeat Normal or Fast Mode according to the speed of your
hand movement.
 If end-points of darkening lesions and inflammation around them are not
obvious after a few minutes, perform a second pass, preferably in a different
direction.
Lumecca is a very powerful Applicator. Take care with treatment
parameters!
 Post-Treatment Recommendations
After each treatment session, the physician should advise the patient on proper care.
Sun block should be used for 3 weeks following the treatment.
Moisturizer and make-up may be applied immediately after each treatment.
