Invasix InMode - Page 91

InMode Without Vasculaze Operator Manual
Section 14: System Specifications

86 of 96
MiniFX Applicator
0.750kg
[1.653 lb]
Diolaze Output Parameters
Wavelength
81010 nm
Fluence
Variable, maintaining highest peak
power
Short
10 – 40 J/cm²
Long
15 – 60 J/cm²
Pulse width (duration)
Short/Long
Light guide cooling
Strong:
2ºC
Normal
10ºC,
Weak
15ºC
Spot size
8 mm x 50 mm
Repetition Rate
Long
0.8 Hz
Short
0.8-1 Hz
DiolazeXL Output Parameters
Wavelength
Fluence
5` – 40 J/cm²
Pulse width (duration)
Short/Long
Light guide cooling
Strong: 7ºC, Normal: 12ºC
Spot size
11 mm x 27.5 mm
Lumecca Output Parameters
Wavelength
515 – 1200nm (SR 515)
580 – 1200nm (SR 580)
Fluence
5 – 30J/cm²
Pulse width (duration)
Short/Long
Light guide cooling
Strong - 15ºC, Normal - 22ºC
Spot size
10mm x 30mm
Repetition Rate
1Hz
